Product features
● Built in high subdivision
● Automatic parameter setting function when power on
● Optical isolation differential signal input
● Pulse response frequency can reach up to 500KHz(Factory default 200KHz)
● Pulse mode/IO mode can be switched freely through dialing
Electrical characteristics
|
Instructions |
Min |
Typical |
Max |
Unit |
|
Continuous output current |
1.0 |
- |
10.2 |
A |
|
Power supply voltage (DC/AC) |
90/70 |
110/220 |
360/253 |
Vdc/Vac |
|
Logic input current |
6 |
10 |
16 |
mA |
|
Logic input voltage |
5 |
5 |
24 |
Vdc |
|
Minimum pulse width of input signal |
0 |
- |
200 |
KHz |
|
Step pulse frequency |
1.5 |
- |
- |
US |
|
insulation resistance |
100 |
- |
- |
MΩ |
Current setting
|
Peak |
RMS |
SW1 |
SW2 |
SW3 |
SW4 |
|
Default[0.1A] |
on |
on |
on |
on |
|
2.10A |
1.50A |
off |
on |
on |
on |
|
2.80A |
2.00A |
on |
off |
on |
on |
|
3.50A |
2.50A |
off |
off |
on |
on |
|
4.20A |
3.00A |
on |
on |
off |
on |
|
5.00A |
3.60A |
off |
on |
off |
on |
|
5.60A |
4.00A |
on |
off |
off |
on |
|
6.20A |
4.40A |
off |
off |
off |
on |
|
6.80A |
4.80A |
on |
on |
on |
off |
|
7.40A |
5.20A |
off |
on |
on |
off |
|
8.00A |
5.60A |
on |
off |
on |
off |
|
8.50A |
6.00A |
off |
off |
on |
off |
|
8.80A |
6.20A |
on |
on |
off |
off |
|
9.30A |
6.60A |
off |
on |
off |
off |
|
9.90A |
7.00A |
on |
off |
off |
off |
|
10.2A |
7.20A |
off |
off |
off |
off |
Function settings
[SW9] Selection of upper and lower edges;
[SW10] Response time;
[SW11] [SW12] Pulse mode/IO mode selection
|
Mode sel |
SW11 |
SW12 |
|
IO internal spontaneous pulse |
on |
on |
|
Potentiometer speed regulation |
on |
off |
|
Double pulse |
off |
on |
|
Pulse+direction |
off |
off |
Subdivision setting/IO internal spontaneous pulse setting
|
Pulse/rev |
SW5 |
SW6 |
SW7 |
SW8 |
IO/RPM |
|
Default[400] |
on |
on |
on |
on |
10 |
|
500 |
off |
on |
on |
on |
20 |
|
800 |
on |
off |
on |
on |
30 |
|
1000 |
off |
off |
on |
on |
40 |
|
1200 |
on |
on |
off |
on |
50 |
|
1600 |
off |
on |
off |
on |
60 |
|
2000 |
on |
off |
off |
on |
80 |
|
3200 |
off |
off |
off |
on |
100 |
|
3600 |
on |
on |
on |
off |
150 |
|
4000 |
off |
on |
on |
off |
200 |
|
6400 |
on |
off |
on |
off |
250 |
|
7200 |
off |
off |
on |
off |
300 |
|
10000 |
on |
on |
off |
off |
400 |
|
20000 |
off |
on |
off |
off |
550 |
|
40000 |
on |
off |
off |
off |
650 |
|
51200 |
off |
off |
off |
off |
800 |
Dimension drawing(mm)
It is recommended to use side installation for better heat dissipation effect.
